57101A 4500/2.0-0.1 Oil Bearing Turbine Expander
Tag No.:57101A
Model:4500/2.0-0.1
Name:Oil Bearing Turbine Expander
1. Design parameters
1.1 First stage expander ET1
Medium |
Nitrogen |
Inlet flow Nm³/h |
4500 |
Inlet pressure MPa (A) |
2.1 |
Inlet temperature K |
157 |
Outlet temperature ℃ |
125.6 |
Outlet pressure MPa (A) |
0.9 |
Efficiency % |
80 |
Gas flow adjustment range |
±20% |
Brake type |
Blower |
1.2 Second stage expander ET2
Medium |
Nitrogen |
Inlet flow Nm³/h |
4500 |
Inlet pressure MPa (A) |
0.9 |
Inlet temperature K |
125.6 |
Outlet temperature ℃ |
86 |
Outlet pressure MPa (A) |
0.2 |
Efficiency % |
84 |
Gas flow adjustment range |
±20% |
Brake type |
Blower |
For more details, please feel free to contact us by email to sinocom6@163.com
Key Words: Oil Bearing Turbine Expander, Turbine Expander, Expander
