54002A 2BV6060 Vacuum pump
Tag No.：54002A
Model：2BV6060
Name：Vacuum Pump
Technical data sheet of vacuum pump
|
Condition requirements |
Conveying medium |
Air |
|
Intake pressure (KPa) (g) |
-90 |
|
|
Exhaust pressure (KPa) (g) |
0 |
|
|
Flow(m³/h) |
27 |
|
|
Intake temperature (°C) |
25 °C |
|
|
Type of working fluid |
Water |
|
|
Working fluid temperature (℃) |
20 °C |
|
|
Working fluid circulation |
Closed loop |
|
|
Performance parameter |
Water ring pump model |
2BV6060 |
|
Intake pressure (KPa) (g) |
-90 |
|
|
Ultimate vacuum (KPa) (g) |
-97 |
|
|
Maximum flow(m³/h) |
27 |
|
|
Speed (r/min) |
2840 |
|
|
Shaft power (KW) |
0.96 |
|
|
Transfer method |
Direct drive |
|
|
Sealed form |
Machinery Seal |
|
|
Working water flow (m³/h) |
0.2 |
|
|
Seal flushing method |
Flush |
|
|
Matching motor |
Model |
YBX3-80M-2 |
|
Power (KW) |
1.1 |
|
|
Power (V×Hz×P) |
380V×50Hz×3P |
|
|
Degree of protection |
F |
|
|
Insulation class |
IP55 |
|
|
Explosion-proof grade |
Exdiibt4 |
|
|
Motor manufacturer |
|
|
|
Material list |
Impeller |
316L |
|
Axis |
2205 |
|
|
Pump body |
316L |
|
|
Pump cover |
316L |
|
|
Disc |
316L |
|
|
Bracket |
HT200 |
|
|
Bearing brand |
SKF |
|
|
Accessories |
Anchor bolts, etc. |
|
