22002A ZZ-25/4.4-Q Steam Boiler

22000 Series-Boiler Equipment

Tag No.:22002A

Model:ZZ-25/4.4-Q

Name:Steam Boiler



The ZZ-25/4.4-Q gas boiler is also composed of three parts: the boiler body, the economizer, and the condenser (or air preheater). But the boiler body, economizer, condenser (or air preheater) are all delivered as a whole. The boiler is also equipped with a single split burner and a blower. This boiler is suitable for industrial power generation, and can also be used for self-provided thermal power plants of large and medium-sized enterprises.



Boiler Design Parameters:

Rated evaporation capacity: 25t/h

Rated steam pressure: 4.4MPa

Rated steam temperature: 450 ℃

Feed water temperature: 104 ℃

Economizer exhaust gas temperature: 144.6 ℃

Condenser exhaust gas temperature: 90 ℃ (feed water temperature 20 ℃)

Boiler design efficiency: 98%

Cold air temperature: 20 ℃

Sewage discharge rate: 2%



For more details, please feel free to contact us by email to sinocom6@163.com
