51011A LFZK-320 Air Filter

51000 Series-Self Cleaning Air Filter

Tag No. :  51011A

Model: LFZK-320

Name: Air Filter



1. Equipment technical parameters

Self-cleaning air filter

Equipment model

GL640



Quantity

1 unit



Name

Technical performance and parameters

Note

1

Air flow (suction status)

30000m3/min



2

Total filtration area

500m3



3

Filtering accuracy

1μm



4

Filtering efficiency

99.99%



5

Filter initial resistance loss

≤150Pa



6

Normal resistance loss

≤600Pa (adjustable)



7

Filter final resistance loss

Customer defined (recommended 500-800Pa)



8

Alarm resistance loss

600Pa (configurable)



9

Dry air reverse purging volume

0.2Nm3/min



10

Purging pressure

0.40.6 Mpa



11

Power consumption

150W

AC220V

12

Installation form

Outdoor vertical



13

Overall dimensions (mm)

2420*2220*2605





For more details, please feel free to contact us by email sinocom6@163.com



Key Words: Air Filter, Self-cleaning Air Filter, Industrial Air Filter
