41005A GY1-260/3 Sweet Gas Dryer
Tag No.:41005A
Model:GY1-260/3
Name:Sweet Gas Dryer
1. Equipment technical parameters
1.1 Zero gas consumption dryer GY1-260/3
|
|
Medium composition |
See SN2.2 |
Input gas flow |
15290Nm3/h |
Rated process flow |
15600Nm3/h(260Nm3/min) |
Regeneration gas consumption flow |
0% |
Design pressure |
3.0MPa |
Work pressure |
2.5Mpa |
Design temperature |
250℃ |
Input temperature |
35℃ |
Pressure loss |
≤0.05MPa |
Regeneration method |
Zero gas consumption heating regeneration |
Dew point of output gas (dehydration degree) |
-60℃ |
Output gas solid particles |
≤3 μm |
Adsorbent |
4A molecular sieve + active alumina |
Adsorbent lifespan |
≥3 years |
Adsorbent filling weight |
4.4t (single tower 2.2t, 10% margin) |
Adsorbent filling structure |
Compact type |
Adsorption tower material |
Q345R |
Work mode |
Fully automatic |
Work cycle |
12 hours (single tower continuous operation for 6 hours, with heating for 230 minutes and adjustable) |
Recycle cooling water consumption |
12.3t/h, 30℃ |
Cooler dimension |
Φ 273mm, L1800mm, heat exchange area 16m2 (25% margin) |
Power supply and consumption |
380V/3PH/50Hz, 130KW (heater with 20% margin) |
Equipment noise |
≤60db(A) |
Nozzle dimension |
DN150,PN40 |
Overall dimension (mm) |
L3800×W2200×H3650 |
For more details, please feel free to contact us by email to sinocom6@163.com
Key Words: Sweet Gas Dryer, Natural Gas Dryer, Heat Regeneration Gas Dryer, Zero Loss Gas Dryer
